This miniature SMD power inductor is produced by a fully automated winding/soldering/testing and packing machine. 100% check before each shipment, the testing included the characteristic inductance value, DC resistance, Isat current and layer isolation. Inductors, also called coils or reactors, are an electrical component that resists changes in electric current passing through them. It consists of a conductor, such as a wire, wound into a coil. When the electric current changes, the magnetic field in the coil induces a voltage, opposing a change in current.
Zxcompo Leadtime:
Zxcompo’s standard delivery time is 1~2 weeks, and fast delivery plans within 3 days are available in urgent cases. This offers customers reliable quality and stable (short) delivery dates (in urgent cases, the delivery date could be 1 day only)
Zxcompo Customization:
In addition to the standard features of our family of specifications, Zxcompo offers low minimum order quantities (MOQs), tighter tolerances, and custom products for different inductance and frequency applications. Our team of engineers has 15 years of experience in this field, we can modify the magnetic core powder to design and produce the most suitable products for customers to meet their applications, design and produce the most suitable products for customers to meet their applications.
Remark: The design is as per the customer’s request specification.
Shape and Dimensions:
Our team of engineers has over 20 years of experience in this field. We design and produce the most suitable products to meet our customers’ application needs. Contact email: sales@ZXcompo.com.
| Part Number |
Dimensions (mm) |
| A(MAX) |
B(MAX) |
C(MAX) |
D |
E(Ref) |
| ZSHC0402 |
4.9 |
4.5 |
2.0 |
1.5±0.3 |
1.0 |
| ZSHC0503 |
5.9 |
5.2 |
3.0 |
2.0±0.3 |
1.0 |
| ZSHC0603 |
7.8 |
7.0 |
3.0 |
3.0±0.3 |
1.8 |
| ZSHC1265 |
14.5 |
13.5 |
6.5 |
3.5±0.5 |
2.5 |
Parameters of SHC Series Inductor
The following are the parameters of this series of inductors produced by Zxcompo. If you need these products, please contact us.
Product Identification:
- Series name.
- Dimensions D×T.
- Inductance: R22-0.22uH 2R2-2.2uH 470-47uH.
- Tolerance: K: ±10% M: ±20% N: ±30%.
